Application:
Mainly used for vacuum heat treatment, vacuum welding and vacuum sintering of high-speed steel, hot and cold working die steel, stainless steel, elastic alloy, high-humidity alloy, magnetic material and titanium alloy.
Technical Features:
1. The heating chamber is made of stainless steel frame, and the heat shield is made of multi-layer graphite felt, which has a long service life and is easy to maintain.
2. The graphite tube heater is used, which is easy to install and maintain, so the rate is low.
3. The air-cooling system consists of a high-power high-speed motor, a high-pressure impeller with a large air volume, a volute and a deflector, a copper tube and copper string heat exchanger and a diversion device, etc.
4. The high-speed circulation of the heater enables the workpiece to be cooled quickly and evenly, and the heating chamber can also adopt an all-metal structure.
5. The electronic control system adopts PLC and programmable temperature controller to realize three control modes: automatic, semi-automatic and manual, and the operation is flexible.
Technical parameter
Maximum humidity | 900℃ |
Temperature control accuracy | ±1℃ |
Furnace temperature uniformity | Full load 15 points 400°C±8°C, Full load 15 points 600°C±5°C |
Ultimate vacuum | 6.6x10A3Pa
|
Pressure rise rate | 0.5 Pa/h |
Air cooling pressure | 2bar |
Dimensions
Model | Effective working size | Loading capacity | Heating power |
HZT-222 | 200mm x200mm x200mm | 20kg | 20kw |
HZT-433 | 450mm x300mm x300mm | 100kg | 40kw |
HZT-644 | 600mm x400mm x400mm | 200kg | 65kw |
HZT-966 | 900mm x600mm x600mm | 500kg | 130kw |
HZT-1177 | 1100 mm x700 mm x700 mm | 800kg | 160kw |
HZTL-80 | Φ500mm x600mm | 200kg | 80kw |
HZTL-1500 | Φ800mm x900mm | 500 | 150kw |
HZTL-200 | Φ1000mm x1100mm | 800 | 200kw |
Furnace structure
1. HZT (single-chamber type),
2. HZTL (single-chamber vertical type)
Configuration options
1. Furnace liner：round metal furnace, round graphite furnace,direction metal furnace,direction graphite furnace,
The standard configuration is a round graphite furnace (2 layers of hard felt + 3 layers of soft felt).
2. Convective stirring:Y (with convection fan), N (without heating convection fan)
3. Standard configuration is N (without heating convection fan)
