Application
Mainly used for diffusion welding of metal materials, ceramic materials, etc.
Structural features
The heat shield has an all-metal radiation shield structure composed of two layers of molybdenum and four layers of stainless steel. The heating element is a wide molybdenum belt, which is evenly arranged along the front, rear, left and right walls to ensure the uniform furnace temperature. The pressure device is composed of a hydraulic station, an oil cylinder, a pressure head, a load cell, a pressure controller and a pressure support, which can realize oil pressure maintaining and pressure setting control. The electronic control system adopts PLC and programmable temperature controller to realize three control modes: automatic, semi-automatic and manual, and the operation is flexible.
Technical parameter
1. Maximum temperature | 1300ºC |
2. Temperature control accuracy | ±1C |
3. Furnace temperature uniformity | ±5ºC |
4. Ultimate vacuum | 6.7×103Pa |
5. Pressure rise rate | 0.5Pa/h |
Diameters
1. Indenter stroke - 80mm-150mm |
2. Indenter diameter - 60mm-200mm |
3. Controllable pressure - 0.02 ton-100 ton |
